Mobile Crushing Plant

STLT’s Newly designed mobile crushing and screening plant systems have the advantages of mobility, flexibility, economy and reliable performance.

Our mobile crushing plant is very appealing for small- to medium-sized projects

> High mobility and flexibility

> Maximise productivity

> Reduce operating costs

Our crushing plant ensures high efficiency, high output, few failures, convenient operation and maintenance.

Get A Free Quote Now!

    Quick Guide:

    6

    models for sale

    Types

    Specs

    Structure

    Case

    Mobile Crushing Plant

    Mobile crushing plants are advanced stone crushing equipment capable of being moved flexibly and operating directly at the site of raw material extraction.

    Two main types of mobile crushers are available, including wheeled and tracked-mounted (crawler) types, which offer further flexibility depending on the specific requirements of the operation.

    Output Capacity:

    85 – 650t/h

    Feeding Size:

    350 – 800mm

    About STLT Mobile Crushing Plant for Sale

    A key advantage of mobile crushing plants is their environmental friendliness and elimination of the need for installation and foundation, which makes them highly efficient for processing a wide range of materials such as limestone, basalt, pebbles, iron ore, and construction waste.

    Moreover, mobile crushers contribute significantly to quarrying efficiency and safety by allowing on-site material processing and reducing the need for extensive material transportation.

    Our crushing plants are renowned for their innovative mobile crushing technology and screening solutions, capable of meeting diverse operational, environmental, and regulatory demands. The main equipment on the production line are all high-performance machines produced with the latest industry technology, with high efficiency, high output, few failures, convenient operation and maintenance.

    The front and back connection design of the maintenance platform is convenient for the operator to observe the equipment operation in time. Inclined up and down escalators, wider pedals, are safer and more convenient than upright ladders.

    Types of Mobile Crushing Plants for Sale

    Mobile crushing plants can be broadly classified into two types: wheel-type crushing plants and crawler-type crushing plants.

    There are also many different types of portable crusher plants, which can be classified according to the type of materials they crush and the working principle.

    Wheel Type Crushing Plant:

    Wheel type crushing plants, also known as tire type mobile crushers, are designed for easy transportation and relocation. These plants are mounted on wheels and require a trailer for traction when moving between sites.

    This type is highly advantageous for projects that necessitate quick site changes due to its flexibility and ease of movement. Additionally, the integrated structure of wheel type crushing plants simplifies installation, allowing operations to commence promptly upon arrival at a site, thereby reducing downtime

    Crawler Type Crushing Plant(track mounted):

    Crawler type crushing plants, on the other hand, are self-propelled and mounted on tracks, allowing them to move independently without the need for external traction.

    This type is especially suitable for rough terrain or uneven ground conditions due to its superior mobility and stability. Crawler type crushing plants are robust and versatile, providing seamless operation in a variety of settings, including construction sites, mining operations, and urban demolition projects. Their compact design and strong adaptability enable them to undertake demanding crushing tasks efficiently

    STLTG Wheeled Mobile Crushing Plant

    STLT wheel-type mobile production lines fully cover the application fields of hard rock, soft rock, and construction waste with a processing capacity of 100-300 tons per hour.

    They are highly suitable for various applications in construction, mining, and demolition projects.

    Features:

    Powerful processing capacity

    Flexible parking function

    STLTG Wheeled Jaw Crushing Plant

    Capacity: 85 – 650t/h

    Max. Feeding Size: 500 – 800mm

    STLTG Wheeled Impact Crushing Plant

    Capacity: 70 – 380t/h

    Max. Feeding Size: 350 – 700mm

    STLT Wheeled Cone Crushing Plant with Vibrating Screen

    Transportation Length: 14500 – 16000mm

    Transportation Height: 400 – 17000mm

    STLT Sand Making Machine with Vibrating Screen

    Transportation Length: 13500 – 16500mm

    Transportation Height: 4350 – 4480mm

    STLTG Crawler Mobile Crushing Plant

    STLT crawler-type hydraulic drive crushing station is a crushing and screening equipment. It is developed by introducing the technology from world famous mining company.

    It adopts the hydraulic system driving crawler to make it run smoothly, it can also adapt to various complex operating conditions.

    Features:

    Save energy

     Crush various materials

    STLTG Crawler Jaw Crushing Plant

    Capacity: 350 – 450t/h

    Speed: 0 – 20m/min

    STLTG Crawler Impact Crushing Plant

    Capacity: 130 – 350t/h

    Speed: 0 – 20m/min

    Specifications of Mobile Crushing Plant

    Detailed Specifications of STLTG Wheeled Jaw Crushing Plant:

    ModelSTLTG938HD86STLTG1149HD98STLTG1349HD110STLTG1349HD125
    Transportation Length(mm)12600135001450015200
    Transportation Width(mm)2600270028002900
    Transportation Height(mm)3870420044504500
    Maximum Length(mm)12500140001610016700
    Maximum Width(mm)4100450051005100
    Maximum Height(mm)4100490050005300
    Weight(t)39576267
    Tire ConfigurationDualaxialtriaxialtriaxiatriaxial
    Jaw CrusherHD86HD98HD110HD125
    Maximum Feeding Size(mm)500550660800
    Discharge opening range(mm)50-15075-175100-200125-225
    Capacity (tn)85-275110-350215-510280-650
    Vibrating FeederZSW380ร—95ZSW420ร—110ZSW490ร—130ZSW490ร—130
    Main Belt Conveyor3800ร—8.5MB1000ร—9.5MB1000ร—11MB1200ร—11M
    side-opening Belt conveyor(optional)B500ร—3MB650ร—3.5MB650ร—4MB650ร—4M
    Genset(Optional)200KW250KW270KW400KW
    Iron remover(optional)RCYD(C)-8RCYD(C)-10RCYD(C)-10RCYD(C)-12

    Detailed Specifications of STLTG Crawler Jaw Crushing Plant:

    ModelSTLTG96STLTG106
    Bin Volume5m8m
    FeederGZDT9538GZDT1145
    Jaw CrusherCJ96CJ106
    Main ConveyorB800X10mB1000X11.5m
    side conveyor(optional)B500X3.2mB650X3.5m
    Iron Remover (optionalRCYD650RCYD800
    Caterpillar400X3.8m500X3.8m
    Speed0-20m/min0-20m/min
    Climbing Abilityยฑ30ยฑ30
    Engine Power96kw106kw
    Total power112.9kw141.4kw
    Overall Dimensions3.5mx3.4mx2.8m14.4mx3.6mx3.0m
    Weight38t52.5t
    Capacity300tpr450tph

    Detailed Specifications of STLTG Wheeled Impact Crushing Plant:

    ModelSTLTG938F1210STLTG938F1214STLTG1149F1315STLTG938F1110STLTG1349F1315
    Transportation Length(mm)120002000139001545015450
    Transportation Width(mm)25502550290029502950
    Transportation Height(mm)390039004450SO(4500
    Maximum Length(mm)1250012500139001545015450
    Maximum Width(mm)32503260325032503250
    Maximum Height(mm)51005200520052005200
    Weight(t)3944546262
    Impact CrusherPE-1210PE-1214PF-1315HD1110HD1315
    Maximum Feeding Size(mm)350350500400700
    Capacity (tn)70-130100-180130-250112280
    Vibrating FeederZSW950ร—3800ZSW950ร—3800ZSW110ร—4900ZSW130ร—4900ZSW130ร—4900
    Main Belt ConveyorB800ร—8.5MB800ร—8.5MB1000ร—9.5MB800ร—11MB1200ร—11M
    Side-opening Belt Conveyor(optional)8500ร—3.2MB500ร—3.2MB650ร—4MB650ร—4MB650ร—4M
    Genset(Optional)320KW320KW400KW320KW440KW
    Iron Separator(optional)RCYD(C)-8RCYD(C)-8RCYD(C)-10RCYD(C)-8RCYD(C)-12

    Detailed Specifications of STLTG Crawler Impact Crushing Plant:

    ModelSTLTG96STLTG106
    Bin Volume5m8m
    FeederGZDT9538GZDT1145
    Jaw CrusherCJ96CJ106
    Main ConveyorB800X10mB1000X11.5m
    side conveyor(optional)B500X3.2mB650X3.5m
    Iron Remover (optionalRCYD650RCYD800
    Caterpillar400X3.8m500X3.8m
    Speed0-20m/min0-20m/min
    Climbing Abilityยฑ30ยฑ30
    Engine Power96kw106kw
    Total power112.9kw141.4kw
    Overall Dimensions3.5mx3.4mx2.8m14.4mx3.6mx3.0m
    Weight38t52.5t
    Capacity300tpr450tph

    STLTG Featured Crushers Used in Crushing Plant

    Crushing plants often incorporate a combination of these crusher types to achieve the desired crushing performance and product quality.

    The choice of crusher type in a crushing plant depends on factors such as feed material characteristics, desired product size, production capacity, and overall plant configuration.

    Here is an overview of the featured crushers commonly used in crushing plants:

    STLTG Cone Crusher

    Overload protection is stable and reliable with a spring-safety device.
    The hydraulic cleaning chamber is simple and quick.
    Discharge opening is adjusted by hydraulic cylinder.
    More evenly linerwear.

    STLTG Vibrating Screen

    Screen angle 18ยฐ , higher screening efficiency
    The exciter is an eccentric shaft and block structure that provides enough exciting force.
    A wear-resistant rubber protective layer has been used at key parts to extend the service life of the screen.
    Thin oil self-lubrication, replace oil once every 3-6 months.

    STLTG Vibrating Feeder

    Multiโ€”layer and high efficient vibrating screen.
    Stable structure, strong exciting force.
    Easy to maintain and durability.
    Wasy to maintain and durability.

    STLTG Jaw Crusher

    Welded fixed steel structure avoids defects.
    Discharging outlet dash adjusting easily.
    Unique fly design, machine run stably.
    Deep-chamber crushing, no dead space.

    STLTG Hammer Crusher

    Cost saveing.
    Low energy saving.
    Wide range of the stone application.
    Cost saving.

    STLTG Impact Crusher

    Big feeding inlet and high crushing chamber.
    With strong rigidity, the rotor has big rotary interia.
    Effectively control the discharging size.
    High chromium, larger impact force

    Wheel Mobile Crushing Plant VS Crawler Crushing Plant

    Here is comparing the key differences between wheel type (mobile) crushing plants and crawler type crushing plants:

    FeatureWheel Type (Mobile) Crushing PlantCrawler Type Crushing Plant
    Mobility– Mounted on wheels, requiring a trailer for traction when moving between sites– Self-propelled, mounted on tracks
    – Highly flexible and easy to relocate– Able to move independently without external traction
    /– Suitable for rough terrain and uneven ground conditions
    Installation– Integrated, modular design– May require more extensive site preparation and installation
    – Simplified installation process, no need for comprehensive foundation setups/
    – Quicker setup and start of operations/
    Versatility– Highly versatile in terms of configuration and combination of various crushing and screening components– Also versatile, but may be slightly less flexible in terms of configuration changes
    – Can be optimized for different production needs
    Capacity– Can be equipped with large-capacity silos for continuous feeding and stable material flow– Capacity may be slightly lower compared to wheel type plants, depending on model
    Transportation Cost– Ability to move the plant to the material site reduces transportation costs– May incur higher transportation costs due to the need to move the entire plant
    Maintenance– User-friendly maintenance platforms and escalators for easier access and inspection– Maintenance may be slightly more challenging due to the track-mounted design

    . Features

    The Advantages of STLT Mobile Crushing Plant

    Adopts modular and universal design, with high structural strength and strong versatility.

    The feeder adopts frequency conversion control, and the feeding amount of the feeder can be adjusted according to different conditions to give full play to the production capacity of the production line.

    The main equipment on the production line are all high-performance machines produced with the latest industry technology.

    The front and back connection design of the maintenance platform is convenient for the operator to observe the equipment operation in time.

    Inclined up and down escalators, wider pedals, safer and more convenient than upright ladders.

    Get A Quote On It Now โ†˜

    Combination Operation With Multiple Machine

    According to the different requirements of customers and various conditions of operation site,We can provide a complete set of solutions, providing combined type optimum design for crushing, screening and transportation,to achieve the best-combined configuration, meeting the demand of customers.

    Internal Structure of STLT Wheel Mobile Crushing Plant

    The wheel-type mobile production lines fully cover the application fields of hard rock, soft rock, and construction waste with a processing capacity of 100-300 tons per hour.

    The main equipment on the production line are all high-performance machines produced with the latest industry technology, with high efficiency, high output, and stable and reliable operation.

    The feeder adopts a vibrating motor to provide excitation force, and accurately controls the feeding amount through a frequency converter to maximize the production capacity of the equipment.

    The jaw crusher adopts a wedge to adjust the discharge opening, which is easy to operate. The integral motor bracket, the belt has good force and long life.

    The cone crusher adopts an automatic control system, which is easy to operate, stable, reliable, high in efficiency and good in particle shape.

    The impact crusher adopts the refined design of the rotor and cavity, the speed and power are reasonably matched to meet the different application options of coarse crushing, medium and fine crushing and material recovery.

    The vibrating screen adopts thin oil lubrication, and the oil change interval is as long as 1200 hours, thelubrication effect is good, and the equipment downtime is short.

    Other Equipment You May Need

    26

    Models

    31

    Models

    19

    Models

    9

    Models

    11

    Models

    Asphalt Plants

    Capacity: 40-320t/h

    Concrete Plants

    Capacity: 25-240mยณ/h

    Concrete Pumps

    Capacity: 30-88mยณ/h

    Rough Terrain Forklift

    Capacity: 0.2-1.2mยณ

    Self Loading Mixer

    Capacity: 1.2-6.5mยณ

    Internal Structure of STLT Crawler Mobile Crushing Plant

    Crawler-type hydraulic drive crushing station is a crushing and screening equipment. It is developed by introducing the technology from a world-famous mining company and combining the real situation. It adopts the hydraulic system driving crawler to make it run smoothly, it can also adapt to various complex operating conditions. This machine is widely used in mineral mining, stone mining, highway (railway)and bridge construction, waste treatment for urban construction and other fields.
    1. The chassis adopts a steel ship structure with high strength and it is highly adaptable to different working sites.
    2. The high-power walking motor is powerful, safe and reliable.
    3. The well-known brand motor achieves good performance of a power system, with features of low noise and energy saving, ete.
    4 . According to the different requirements of customers, we can provide different crushing and screening equipment and combined type optimum design, and we fully guarantee the quality.
    5. The generator set can be equipped, to work normally under complex situations, such as the situation of no power or sudden power off, ensuring continuous operation and reducing unnecessary loss.

    Benefits of Our Crawler Mobile Crushing Plant

    The crawler-type mobile crushing plant is an advanced piece of equipment developed by incorporating technology from renowned mining machinery companies and adapting it to the conditions in China.

    This machine utilizes a hydraulic system to power the crawler tracks, enabling smooth operation and the ability to adapt to a wide range of challenging job site environments.

    As a result, it finds extensive applications in mineral extraction, stone quarrying, highway and railway construction, bridge projects, urban waste management, and numerous other sectors.

    The material to be processed is evenly fed into the jaw crusher through the feeder. After the initial size reduction, the material is conveyed to the impact crusher for secondary crushing.

    Following this stage, the crushed material is then directed to the vibrating screen. Any material that does not meet the desired specifications is returned to the crushing process to be re-processed.

    This entire workflow represents a complete production line, allowing for the cyclical crushing of materials to fulfill the specific requirements of the customers.

    Primary Mobile Crushing Plant VS. Secondary Mobile Crushing Plant

    Primary mobile crushing plants and secondary mobile crushing plants are two distinct types of mobile crushing solutions, each serving a specific purpose in the overall crushing process.

    Primary Mobile Crushing Plant:

    • The primary mobile crushing plant is responsible for the initial size reduction of the raw material.
    • It typically consists of a robust jaw crusher or gyratory crusher as the main crushing unit.
    • The primary crusher is designed to handle larger, coarser feed materials and break them down into smaller, more manageable sizes.
    • The primary mobile crushing plant is often the first step in a multi-stage crushing and screening operation.
    • It is commonly used in applications such as quarrying, mining, and construction and demolition waste processing.
    • The primary mobile crusher helps to prepare the material for further processing in the secondary and tertiary stages.

    Secondary Mobile Crushing Plant:

    • The secondary mobile crushing plant is used for the next stage of size reduction after the primary crushing.
    • It usually incorporates an impact crusher or a cone crusher as the main crushing unit.
    • The secondary crusher is designed to handle the pre-crushed material from the primary stage and reduce it further to the desired size specifications.
    • The secondary mobile crushing plant helps to refine the particle size distribution and produce more uniform, higher-quality end products.
    • It is commonly used in applications where finer aggregates or specialized products are required, such as in concrete production, asphalt manufacturing, and industrial mineral processing.
    • The secondary mobile crusher works in conjunction with the primary mobile crusher to achieve the overall crushing objectives.

    The combination of primary and secondary mobile crushing plants allows for a more efficient and versatile crushing operation, enabling the processing of a wide range of materials to meet the specific needs of various industries.

    Why Choose US?

    After long-term technology research and international exchange, qualities and technology contents of STLTG products have achieved international top level and received wide recognition and praise in the international market.

    STLTG products are exported to more than 9(countries and regions such as Indonesia, the United States, Malaysia, Philippines, Fiji, Trinidad and Tobago, Zimbabwe, Kenya, etc.

    Being customer-oriented, we are committed to providing the best solutions and turn-key projects for global customers; and relying on an advanced customer service platform, we provide customers with comprehensive, complete and 24-hour one-stop services.

    STLTG immutably ranks customers first and credit foremost. We are looking forward to achieving a win-win situation with you by first-class technology, first-class products and first-class service!

    STLT Mobile Crushing Plant in Samoa

    Get Customized Solution

    STLT Mobile Crushing Plant in Malaysia

    Get Customized Solution

    STLT Crushing Plant Combination Fiji

    Get Customized Solution

    STLT Stone Crushing Plant in Philippines

    Get Customized Solution

    . Certifications

    Our Certifications
